ABB ACS310 0.37KW 1.3A IP20 PUMP & FAN DRIVE W/O CP ACS310-03E-01A3-4
ABB ACS310 0.37KW 1.3A IP20 PUMP & FAN DRIVE W/O CP ACS310-03E-01A3-4
Regular price
Regular price
Sale price
Unit price
per
Tax included.
Couldn't load pickup availability
The ACS310 drives are designed for squared torque applications such as booster pumps and supply and return fans. The drive includes a powerful and beneficial set of features designed for pump and fan applications. These features include built-in PID controllers and pump and fan control (PFC) that varies the drive’s performance in response to changes in pressure, flow or other external data.
Product Data | Product Catalog
| Application | Domestic & Commercial |
| Communication Protocol | MODBUS |
| Contains | PC Connection |
| Dimensions (mm) | 132W x 344H x 217D |
| EAN | 6410038785710 |
| Input Voltage AC (V) | 380 - 480 |
| Maximum Output Frequency (Hz) | 500 |
| Maximum Output Voltage AC (V) | 480 |
| No. of Analogue Inputs | 2 |
| No. of Analogue Outputs | 1 |
| No. of Digital Inputs | 5 |
| No. of Digital Outputs | 1 |
| Nominal Output Current (A) | 1.3 |
| Number of Other HW Interfaces | 1 |
| Number of RS-232 Interfaces | 1 |
| Number of RS-485 Interfaces | 1 |
| Output Power - Normal Duty (kW) | 0.37 |
| Relative Symmetric Net Frequency Tolerance | 5% |
| Relative Symmetric Net Voltage Tolerance | 10% |
