Pixsys PL600 | Modular PLC - OPC-UA Server / MQTT
Pixsys PL600 | Modular PLC - OPC-UA Server / MQTT
Couldn't load pickup availability
Pixsys PL600 PLC relies on a modular and flexible structure. The CPU is based on an ARM CORTEX A8 -1 GHz microprocessor and is conceived as control and connectivity node, complete with RS485 and RS232 serial (Modbus RTU), Ethernet (Modbus TCP), CANopen.
The various analogue-digital I/O combinations are provided by PLE500 modules, which communicate with the CPU via internal real-time bus on DIN rail. MCM260X series is available for remote I/O acquisition and management.
To ensure Industry 4.0 connectivity, the Modbus TCP protocol is supported, as well as MQTT and OPC-UA Server, which are available as built-in functions in the LogicLab development tool.
Product Features
|
Power supply |
12..24 V DC ±15% 50/60 Hz - galvanic isolation 2,5kV |
|
Power consumption |
3 Watt/VA |
|
Processor |
ARM Cortex A8 @ 1 GHz |
|
Memory |
eMMC 2 GB / RAM 512 MB DDR3 |
|
Clock |
Real-Time clock, Back-up battery, CR2032 Lithium / Manganese Dioxide (Li/MnO2) |
|
Serial communication |
1x RS485 (1200..115200 Baud) galvanically isolated |
|
CAN |
1x CAN (50K..1Mbit) galvanically isolated |
|
Expansion Bus |
PLE-DIN-BUS (real time)on DINrail - MAX 24 modules PLE500 |
|
Ethernet |
1x 10 / 100 Mbit/s 1x second Ethernet port option on USB (see accessories) - 10 / 100 Mbit/s |
|
USB |
1x USB 2.0 |
