PL700 | Modular PLC CODESYS
PL700 | Modular PLC CODESYS
Couldn't load pickup availability
PL700 is the Pixsys PLC CPU integrating Codesys Control SL v.3.5.16.20 runtime, programmable by CODESYS development environment.
CPU supports wide range of fieldbus systems:
- CODESYS CANopen Manager / Device
- CODESYS EtherCAT Master
- CODESYS EtherNet/IP Scanner / Adapter
- CODESYS J1939
- CODESYS Modbus TCP Master / Slave
- CODESYS Modbus Serial Master / Slave
- Controller / periphery CODESYS PROFINET
Connectivity for Industry 4.0 is ensured by protocol OPC UA Server (full version for data exchange) and MQTT protocol (available as function block)
Runtime functionalities may be expanded purchasing additional packages from Codesys Store:
- CODESYS BACnet SL
- CODESYS KNX SL
- CODESYS SoftMotion SL
- CODESYS SoftMotion CNC+Robotics SL
Built-in CODESYS WebVisu enables activation of a "Virtual HMI" to display customized synoptics in a browser on a Pixsys Web panel or on a PC.
Acquisition of local I/Os is possible via integrated fieldbus PLE-DIN-BUS for the Pixsys modules PLE500 and via RS485/ModbusRTU or CANopen for Pixsys MCM260X.
Preliminary step to program PL700 in Codesys is the installation of "CODESYS Control for PL700 3.5.16.20 package" available for download.
Product Features
|
Power supply |
12..24 V DC ±15% 50/60 Hz - galvanic isolation 2,5kV |
|
Power consumption |
3 Watt/VA |
|
Processor |
ARM Cortex A8 @ 1 GHz |
|
Memory |
eMMC 2 GB / RAM 512 MB DDR3 |
|
Clock |
Real-Time clock, Back-up battery, CR2032 Lithium / Manganese Dioxide (Li/MnO2) |
|
Serial communication |
1x RS485 (1200..115200 Baud) galvanically isolated |
|
CAN |
1x CAN (50K..1Mbit) galvanically isolated |
|
Expansion Bus |
PLE-DIN-BUS (real time) on DINrail - Max 24 modules PLE500 connectable |
|
Ethernet |
1x 10 / 100 Mbit/s optional second Ethernet port 10 / 100 Mbit/s on USB (see accessories) |
|
USB |
1x USB 2.0 |
